1. Support a wide range of test frequencies, 9kHz-4000MHz
2. Maximum support 20MHz demodulation bandwidth
3. Built-in GPS receiver, convenient for field testing
4. Strong anti-distortion performance, third-order cut-off point (IP3): +15dBm
5. Maximum safe input level +30dBm (peak power/entry attenuation >15dB)
1. With GSM/GPRS/EDGE, CDMD, CDMA2000/EVDO, WCDMA/HSPA+, TD-SCDMA, TDD-LTE/FDD-LTE signal demodulation analysis
2. Can test the base station RF wireless indicators, items include: RF output power, occupied bandwidth, frequency error, adjacent channel rejection ratio ACLR, etc.
3. Support signal coverage test, including clear frequency test, indoor and outdoor road test, etc.
4. Ultra-long battery life, more than 8 hours of continuous use
5. Superior portability, product weight 3.4kg
1.Pre-base station construction clearing frequency test
2.Mode test and coverage test in network construction
3.Monitoring of radio signal environment
4.Monitoring the power of legal transmitters in designated frequency bands
5. Closed-loop testing of RF performance and signal quality of base stations
6. Open-loop null detection of the signal quality of the base station
