1.Monitoring frequency range: 100kHz-8GHz
2.Directional frequency range: 10MHz-8GHz
3.Medium frequency bandwidth: 40MHz
4. Scanning speed: 50GHz/S
5. Directional sensitivity: 15dBμV/m
6. Monitoring sensitivity: 10dBμV/m
7. Directional measurement time limit: 2ms
8. Directional accuracy: 2°
9. Polarization mode: vertical
10. Directional measurement system: Watson Watt / related interference
Trouble-free time: 4 years
10 groups of sub-frequency preselectors at the front of the receiver to ensure the dynamic range of the whole machine. No intermodulation dynamic range of 115dB;
Support for POE power supply, allowing for shorter feeder lines and higher system sensitivity.
Fast processing speed, 100% capture probability at 75% FFT overlap 3.125μs;
IP67 protection level, -40℃ to +85℃ can work 7*24 hours
100V/m super anti-disturbance capability
Support for pitch-angle vectoring.
Monitoring and direction finding sensitivity of less than 15 dBμV/m.
Fast-distribution monitoring system
Fixed monitoring station [four types
Fixed monitoring directional station [three types
