Delivers best-in-class wavelength accuracy
Ideal for transceiver testing, manufacturing and DWDM analysis
Replaces wavelength meter and OSA combinations with performance-enhanced OSA
High wavelength accuracy in a compact form factor
Perfect for system vendors and transceiver manufacturers
Plugs into the LTB-8 or FTB-4 platform
Lifetime automatic wavelength adjustment using gas chamber reference
Remote control via SCPI commands
Spectral measurements
Wavelength range (nm): 1250 to 1650
Wavelength uncertainty (pm): ±4 ±10
Resolution bandwidth (FWHM) (nm): 0.05
Wavelength linearity (nm): ±0.003
Wavelength repeatability (nm): <0.001
Analysis modes: WDM, EDFA, drift, spectral transmittance, FP, DFB
Power Measurement
Dynamic range (dBm) (per channel): -80 h to 18
Maximum safe total power (dBm) : 23
Absolute power uncertainty (dB) : ±0.5
Power repeatability (dB): ±0.02
Transceiver Testing, Manufacturing and DWDM Analysis
System vendors and transceiver manufacturers
