Single-ended testing efficiency: conduct CD/PMD tests on multiple links from a single location, minimizing truck rolls and reducing operational expenses (OPEX)
Impressive dynamic range: up to 37 dB with reflector (30 dB without reflector)
Rapid and accurate: achieve CD and PMD results as well as getting length and delay measurement results, in 25 seconds
Extensive band coverage: O and SCL bands
Standards compliance: adhere to industry standards (e.g., ITU‑T G.650.3, TIA‑455‑243,
TIA‑455‑175‑C and IEC 61282‑9)
Single-button operation: avoid human errors and get the right results the first time
Connectivity: leverage cloud-hosted capabilities for job management and reporting with EXFO Exchange and FastReporter 3 while ensuring operational compliance across teams
Measured wavelength range (nm) SCL-band 1475 to 1626 ，O-band 1310 ± 1
Dynamic range (dB) SCL-band 30 (37 with reflector)
Distance uncertainty (km) ±(0.01 + 1 % × distance)
Test time (s) b 25
Link length
Range (km) c 1 to 240
Distance uncertainty (km) ±(0.01 + 1 % × distance)
CD
CD uncertainty (ps/nm) d, e ± 2.5
Zero dispersion wavelength in SCL-band (nm) for G.653, G.655.C, G.655.D f ± 1.5
PMD g
PMD display range (ps) 0.1 to 35
PMD uncertainty (ps) e, h ±(0.2 + 5 % × PMD)
Qualification of links up to 400G/800G and beyond
Metro, core, DCI and cellular/mobile xhaul network testing
Fully compliant fiber characterization (with fiber testing tools and cloud-hosted capabilities)
