1) Portable and lightweight, easy to use, rechargeable battery power supply, one person can operate, four tests completed at one time.
2) Digital design, software control, stable and reliable performance.
3) Large LCD interface, Chinese display, easy to understand at a glance, easy to learn, easy to understand.
4) The measured information is provided to the operator in three ways: digital size, grating length, sound slow, so that the test
process easy and comfortable.
(5) automatic and manual adjustment of the receiver.
(6) receiver real-time display of the measured target pipeline cable depth and current.
(7) transmitter constant power output, automatic matching, to ensure that the machine works in the best condition.
8) with backlight function, adapt to night operation
Transmitter parameters.
(1) output signal: output more than 10 kinds of frequency sinusoidal AC signal.
(2) output power: constant power output, maximum not less than 10 watts (3) output mode: direct connection method, coupling method, induction method.
4) With ohm meter function, can measure external impedance.
5) Load matching: fully automatic impedance matching.
(6) display interface: large LCD Chinese, graphic display, with backlight.
7）Weight: 3.0 kg
Receiver parameters
1）Receiving frequency: receive 8 different frequencies, respectively, 50Hz, 577Hz, 815Hz, 8kHz, 33kHz, 65.5kHz, 82kHz, 65.5kHz, 82kHz, 65.5kHz, 65.5kHz.
65.5kHz, 82kHz, 133kHz.
2) Receiving mode: wide peak mode, trough mode, external device mode. With left and right arrows to indicate the position of the pipe.
(3) signal interface: digital size, grating length, sound slow three interfaces at the same time to indicate the signal strength, dynamic
State range is 0~999, can indicate the maximum signal strength.
(4) display interface: LCD display, graphic display, LCD backlight brightness can be manually switched.
(5) gain control: automatic and manual adjustment, dynamic range 0~100dB. (6) detection length: when directly connected to the cable, the longest 15KM.
Coupling cable, a coupling can be measured 3Km, multiple coupling infinite distance. Induction cable, one induction can be measured
300m, multiple induction infinite distance.
(7) depth measurement: direct reading detection depth, range 0~6.00m
(8) current measurement: direct reading current, range 000 ~ 999mA
(9) detection accuracy: 0 ~ 3m for burial depth of 5%, 3 ~ 6m for burial depth of 10%
10）Weight: 1.3 Kg
For fiber optic cable path location, depth measurement
Identification of fiber optic cables
