Equipped with the unique PON-aware™ feature, which automatically detects the PON technology used
Compatible with GPON and EPON networks
Supports 10G PON networks
Supports pass-through mode for ONT/ONU authentication
Provides Bluetooth® and USB connectivity
Uses smart applications to save and share test results and create test reports
Compact, rugged, and IP54 enclosure-compliant
Rechargeable battery for up to 8 hours of continuous use
Storage capacity: up to 3500 results
Battery life: 8 hours (continuous use)
Measurement units: dB, dBm
Dimensions (H x W x D) 154 mm x 88 mm x 41 mm
Display size: 2.7 inches
Weight: 420 g
Single-layer PON service activation
Multi-layer PON service activation
Insertion loss measurement
Multiple PON technologies can be supported by a single device.
- GPON (ITU-T G984.2)
- EPON (IEEE 802.3)
- XG(S)-PON (ITU-T G987.2)
- TWDM NG-PON2 (ITU-T G989.2)
- RF Overlay
- RFoG (ANSI/SCTE 174 2010)
