Simultaneous measurement of all PON signals anywhere on the network
Innovative workflow management for increased test efficiency
More rugged and weatherproof design
Use of protected data formats to ensure the authenticity of test results
1. FTTx mode: power measurement range - continuous data stream through the region (dBm)
1310 nm: 8 to -40
1490 nm: 12 to -40
1550 nm:25 to -40
Burst Measurement Function: CO to ONT
Burst measurement range (dBm): 1310 nm 8 to -30
ORL (dB): 1550 nm 55
Pass-through insertion loss (dB): 1.5
Power Uncertainty (dB): 0.5
Calibration wavelength (nm): 1310/1490/1550
Threshold groups: 10 configurable threshold groups with threshold naming
2. OPM mode (broadband CW)
Burst measurement range (dBm)
1310 nm/1490 nm/1550 nm:25 to -40
ORL (dB): 1550 nm 55
Power Uncertainty (dB): 0.5
Calibration wavelength (nm): 1310/1490/1550
BPON, EPON and GPON Configuration
Service activation and troubleshooting
Data storage and reporting capabilities
